12.6V, 13.8v, 14.6V, 60A, 100A, 110A, 115A, 1500w, 1600w high-power automotive programmed voltage stabilizing power supply, 4-string lithium iron phosphate charger, 3-string ternary lithium charger, lead-acid battery charger.

Modified with a switch power supply from a well-known brand server, it is the first choice for stability. The heat dissipation method has been improved. Whether it is low-power output or full-load output, the temperature of the internal components is controllable (the difference is that the same type of modification from the same industry generates a lot of heat). With a maximum conversion efficiency of 94% and overcurrent protection in place.

Cooling method: Active current-controlled fan + passive temperature-controlled fan. Fans below 85A are gentle, while those above 100A are not silent. Those who are obsessed with fan noise should think it through before shooting

"Charger Parameters"

Input voltage: AC 200-240V 50-60HZ

Output voltage: Adjustable from 5 to 15V DC

Output current: Adjustable from 3 to 60A, 3 to 100A, and 3 to 115A (Only constant current and constant voltage can be used as a charger)

Continuous power: Output 750W, 1200W, 1500W

Peak power: Output 750W, 1200W, 1500W, output 1600W

Voltage error accuracy: +-0.1V

Current error accuracy: ±1-3A

Charging method: Constant current first, then constant voltage. When fully charged, the current automatically returns to zero. When the current display shows 0, it is fully charged

Protection methods: The positive and negative pole clamps have short-circuit protection, the machine has over-temperature protection, fan self-check, abnormal protection, overvoltage and overcurrent protection.

It has no anti-reverse connection function. If the positive and negative terminals are connected incorrectly, the charger will be damaged. If they are connected in reverse, it will be damaged. If they are connected in reverse, the output rectifier tube will blow out. If it is damaged by reverse connection, there is no warranty!Features

Input voltage: AC 110-240V 50～60HZ

Output voltage: DC 3-15V adjustable

Output current: 3-100A/ 3-62A adjustable (only constant current and constant voltage can be used as a charger)

Rated power: output 1200W/600W

Peak power: output 1500W/930W/W750

Maximum current: output 100A (generally used for automotive programming voltage regulation)

Continuous current: output 85A (24 hours non-stop charging lithium battery)

It is not a false standard of power supply, but the principle of power supply use must be understood, and a little margin should be left in everything.

Voltage error accuracy: +-0.1V

Current error accuracy: +-2A

Charging method: constant current and constant voltage, self-stop when fully charged, when the current shows 0, it is fully charged

Accessories include: 1 charger, 1 input cable

Work Conditions:

Ambient temperature: -5 - 40℃

RH: 5 - 95%

Max. altitude: 10000 meter

Cooling: chargers use of forced air cooling system. Under dustless and ventilated conditions, the full load temperature rise not exceeding 40℃.

Storage conditions

Ambient temperature: -40 - 70℃

RH: 0 - 95%

Max. altitude: 20000 meters.

Note:

1: connect the battery after adjusting the voltage, please do not adjust the voltage after that.

2: do not reverse connection, otherwise it will burn out.
